Compensated PC Power Supply Mn Zn Isolation Coupler Radio Cassette Player PLC Coupling Transformer

Power Line Broadband Carrier Signal Coupling and Isolation Technology Solution

  • Protection level :

    IP67, IP68
  • Certification :

    UL, CE
  • Material :

    Mn, Zn
  • Usage :

    Radio cassette player

Introduction:

Coupling transformer, that is, the radio line is often used as a coupling transformer between the poles. For example, the center periphery, input transformer and output transformer of a radio belong to this category. The role of coupling transformer is multi-faceted, it can also be used to achieve impedance matching.

Products are used in automotive electronics, televisions, DVD/VCD, telephones, electronic toys, mobile communication equipment, lighting, medical equipment, computer products and peripherals, network xDSL filters, modems, global positioning systems, AC-DC/DC-DC Converters, up/down converters, amplifiers, audio-visual equipment, audio equipment, noise filters, power supplies, analyzers, displays, switching regulators, SCR and TRIAC control circuits, automation systems, etc.



NO Item Test Pin Test Value Condition
1 Inductance 1-2 / 5-6 13uH MIN 100KHZ 0.1V
2 DC Reasistance 1-2 / 5-6 42mΩ MAX TH2512B
3 Voltage N1 / N2   N1 / N3 4500VAC 60S / 1mA
4 Working Frequency N1-N2-N3 1MHZ-30MHZ

Applications:

  •  Compact fluorescent lamp
  •  Television receiver
  •  Radio cassette player
  •  PC power supply
  •  Monitor,audio,VCD,DCD
  •  UPS
  •  The electronic apparatus
  •  The noise rejection
  •  Induction cooker,etc.



Feature:

  •  High current capacity
  •  Low core loss at frequency
  •  High reliability, efficiency
  •  Small packaged size
  •  Operating Temperature: -30°C to +80°C
  •        Electrical Specifications at 20°C



Hemei Electronics is a power line broadband carrier signal coupling isolation technology solution partner, we have perfect R&D and production of signal coupling transformer technology, if you need this type of product, please leave a message below.
