Coupling transformer, that is, the radio line is often used as a coupling transformer between the poles. For example, the center periphery, input transformer and output transformer of a radio belong to this category. The role of coupling transformer is multi-faceted, it can also be used to achieve impedance matching.
Protection level :
IP67, IP68Certification :
UL, CEMaterial :
Mn, ZnUsage :
Radio cassette playerIntroduction:
Products are used in automotive electronics, televisions, DVD/VCD, telephones, electronic toys, mobile communication equipment, lighting, medical equipment, computer products and peripherals, network xDSL filters, modems, global positioning systems, AC-DC/DC-DC Converters, up/down converters, amplifiers, audio-visual equipment, audio equipment, noise filters, power supplies, analyzers, displays, switching regulators, SCR and TRIAC control circuits, automation systems, etc.
| NO | Item | Test Pin | Test Value | Condition |
| 1 | Inductance | 1-2 / 5-6 | 13uH MIN | 100KHZ 0.1V |
| 2 | DC Reasistance | 1-2 / 5-6 | 42mΩ MAX | TH2512B |
| 3 | Voltage | N1 / N2 N1 / N3 | 4500VAC | 60S / 1mA |
| 4 | Working Frequency | N1-N2-N3 | 1MHZ-30MHZ |
Applications:
Feature:
